Product Details:
|
| Application: | Ditch Bucket | Material: | Q355B, NM400 |
|---|---|---|---|
| Condition: | Brand New | Customization: | Color |
| Volumn: | 0.8-2.2 Cbm | Shape: | Triangle |
| High Light: | PC200 Trapezoidal Ditch Bucket,CAT315 Trapezoidal Ditch Bucket,CAT320 Excavator Bucket |
||
Catalogue ZH excavator boom arm.pdf
A V-groove bucket is an excavator bucket designed specifically for digging narrow, deep trenches, or "ditches." It is ideal for digging trenches that are too small or too deep for standard buckets. It is also commonly used for excavating sewer pipes and other drainage structures
| Volunm(cbm) | excavator model(ton) | weight(kg) |
| 1 | 20T | 1270 |
| 1.1 | 20-22T | 1200 |
| 1.2 | 22-24T | 1300 |
| 1.3 | 24-27T | 1400 |
| 1.5 | 28-30T | 1600 |
| 1.6 | 30-35T | 1700 |
| 1.8 | 36-38T | 1900 |
| 2 | 40-45T | 2100 |
| 2.2 | 40-45T | 2400 |
| 2.5 | 50-55T | 2700 |
• Hardened steel sides and reinforced bottom
• Wide range of sizes to fit most excavators
• Self-sharpening teeth for improved performance
• Holes for easy bolt-on tooth installation
1. The V-Ditch Bucket allows the excavator to quickly dig a V-shaped trench in a variety of soil conditions.
2. It is designed to allow the excavator to dig a very precise trench, even in tight spaces.
3. It is easy to use and can be adjusted to dig a variety of depths and widths.
1. Standard bucket
Q355B material, standard plate thickness, and China high-quality bucket tooth base. It is mainly applicable to light operation occasions such as excavation of general clay and loading of sand, soil and gravel.
Q355B material, NM400 optional. Based on the standard bucket, reinforcing plates are added at the bottom, and the tooth plate and side plate are thickened. It is mainly applicable to heavy and light industrial occasions such as excavation of hard soil and loading of soil, gravel and gravel mixed with soft sand.
3. Heavy duty rock bucket:
Q355B+Hardox500. Based on the reinforced bucket, the bottom plate and side plates are thickened. It is mainly applicable to the excavation of hard rocks, secondary hard rocks and wind fossils mixed in the soil; Loading of hard rock and ore after blasting.
1. 14000㎡ Workshop with Precision Equipments
2. High-tech R&D Team
3. Experienced Workers
4. Customization
5. Prompt Lead Time (7-15 days)
6. Excellent Service
CE certification & Utility model patent certificates
