Guaranteed Long Reach Excavator Dipper Arm 10M-18M With Bucket and cylinder for CAT

Description
Applicable Industries: Construction Works Video Outgoing-inspection: Provided
Warranty: 1 Year Application: Excavator
Material: Q355B MOQ: 1 Set
Apply To: Universal Usage: Machinery Attachment
Delivery Time: 6-27 Days

Two Section 40-47T Excavator Stick Extension Long Reach

18 Meters with Bucket Excavator Dipper Arm


For more products:

Product Presentation of Excavator Boom

Enhanced Excavator Boom Design for Heavy-Duty Applications

The excavator’s boom is constructed from high-strength Q355B steel, ensuring optimal durability and structural rigidity. For the extension arm sleeve, 45# steel is used as the base material, reinforced with a 40Cr bushing lining to enhance wear resistance.

To minimize shear stress caused by the frequent rotation of the shaft and sleeve, lubrication (butter grease) is applied, significantly extending the sleeve’s service life.

A key feature of this design is the extension arm positioned between the body support and the working arm. This component is hydraulically driven by dedicated oil cylinders, working in tandem with the bucket cylinder to maximize operational efficiency.

The system is equipped with dual control interfaces (inside and outside the cockpit), with each hydraulic cylinder set operating independently for precise maneuverability.

Ideal Applications:

  • Mining operations

  • Port logistics & material handling

  • Emergency flood control & rescue missions

This innovation represents a major advancement in mining machinery, delivering superior performance and long-term reliability in demanding environments.


 Material Use  Q345B, Q550D, Also can customize to customer requirements
 Product Warranty Period  6 months,9 months,1 Year
 Product Size  Most lengths can be 34M, According to customer requirements, Any excavator model



Guaranteed Long Reach Excavator Dipper Arm 10M-18M With Bucket and cylinder for CAT 0



Advantages of Zhonghe Excavator Long Arm

1. Less maintenance
Using high quality materials, such as Q355B as default, Q690D optional, Niningbo connectors, seamless precision pipelines, graphite alloy copper sleeve, and strong but light bucket cylinder.

2. Strong and sturdy
Built-in reinforcing ribs. Professional welding skills towards the different bearing positions. Groove preparation(45° edge-mining) before welding.

3. Tolerance within 5-10um
Hole drilling tolerance is within 5-10um, ensure accuracy.

4. Reach deeper and higher
The max work range and the max digging height are larger as the angle of the boom and arm can reach 163 degrees.

5. High work efficiency and saving fuel
Lighter while taking into account the quality, not only ensures work efficiency but also saves fuel.

6. Fillet weld testing
We can determine the quality of a fillet weld joint by performing NDT and mechanical testing. Macro examinations and fillet fracture tests give a good view of the profile, fusion, and penetration, and reveal whether there are any imperfections, such as porosity or inclusions, in the weld. These tests are used to test the welder’s ability to weld a fillet weld.
Guaranteed Long Reach Excavator Dipper Arm 10M-18M With Bucket and cylinder for CAT 1

What Zhonghe Can Do



CUSTOMIZATION:
1. Applicable for all brand excavators.
2. Color, length, and material can do according to you.
3. Extra pipelines can be added to suit some extra applications.
4. Boom cylinder and stick cylinder can also be supplied if the customer wants.

STRONG PRODUCTION CAPACITY:
We can produce 50 sets of excavator booms per month.
Our annual output of various types of excavator boom arms can reach 600 sets.

GOOD SERVICE:
1. Online support within 24 hours.
2. Appointment video technical support.
(Our engineers have focused on excavator boom and attachment for over 10 years)
3. Long excavator boom shall be two/three jointed pcs to make it fittable into a container to save shipping costs.

Warranty:
1 year for long reach boom, 180 days for cylinder and linkage, and 90 days for the bucket.


Guaranteed Long Reach Excavator Dipper Arm 10M-18M With Bucket and cylinder for CAT 2

All parts you needed are included.

Long Reach Kits Are Fully Compatible with ZHONGHE Excavator Standard Buckets, and Cylinder.
Excavator long boom
Excavator long arm
Standard bucket
Linkage kit
Bucket cylinder
Butter hose
Pin
Lubricating system
Seals



Guaranteed Long Reach Excavator Dipper Arm 10M-18M With Bucket and cylinder for CAT 3
