Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm

Place of Origin Guangdong, China
Brand Name ZH
Certification CE
Model Number ZH-JCB22
Minimum Order Quantity 1set
Price $14000/Pieces
Packaging Details Bubble bag packaging
Delivery Time 15works
Supply Ability 60 Piece/Pieces per Month
Product Details
Condition 100% Brand New Material 0355B/0690D Optional
Application All Brand Excavators Suitable Length 16-30m Optional
Payment Terms T/T, Discussion Supply Ability 50 Piece/Pieces Per Month
Port Shenzhen Shekou (Port) Certification CE Certificate
High Light

Q550D Excavator Boom Arm

,

Excavator Boom Arm 16m

,

30m Long Reach Arm

Leave a Message
Product Description

Custom Excavator Boom Arm , Doosan DX340 DX330 DX230 Excavator Long Reach Arm


See what product zhonghe can do: Catalogue ZH excavator boom arm.pdf
For more products:

Product Presentation of Excavator Boom

 Material Use Q345B, Q550D, Also can customize to customer requirements
 Product Warranty Period 6 months,9 months,1 Year
 Product Size Most lengths can be 34M, According to customer requirements, Any excavator model.



Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 0



Advantages of Zhonghe Excavator Long Arm

1. Less maintenance
Using high-quality materials, such as default Q355B, optional Q690D, Ningbo connectors, seamless precision pipes, graphite alloy copper sleeves, strong and lightweight barrels.

2. Sturdy and sturdy
Built-in stiffeners. Professional welding skills for different bearing positions. Groove preparation before welding (45° edge excavation).


Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 1

What Zhonghe Can Do



CUSTOMIZATION:
1. Applicable for all brand excavators.
2. Color, length, and material can do according to you.
3. Extra pipelines can be added to suit some extra applications.
4. Boom cylinder and stick cylinder can also be supplied if the customer wants.

GOOD SERVICE:
1. Online support within 24 hours.
2. Appointment video technical support.
(Our engineers have focused on excavator boom and attachment for over 10 years)
3. Long excavator boom shall be two/three jointed pcs to make it fittable into a container to save shipping costs.

Warranty:
1 year for long reach boom, 180 days for cylinder and linkage, and 90 days for the bucket.


Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 2

All parts you needed are included.

Long Reach Kits Are Fully Compatible with ZHONGHE Excavator Standard Buckets, and Cylinder.
Excavator long boom
Excavator long arm
Standard bucket
Linkage kit
Bucket cylinder
Butter hose
Pin
Lubricating system
Seals



Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 3



Specification of Excavator Boom Arm

Weight
Model
Part Length
Total length(m)
Weight(kg)
Maximum removal height(m)
Total Length(mm) 25T 8.5 16 2800 16M
Boom(A)(mm) 2.3 900
Arm(b)(mm) 5.2 1700
Maximum Digger Radius(C)(mm) 30T 9.5 18 3000 18M
Maximum Digger Depth(C)(mm) 2.3 1000
Maximum Unloading Height(E)(mm) 5.2 1950
Maximum Digger Height(F)(mm) 35T 10.5 20 3500 20M
Bucket Volume(m³) 2.3 1100





Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 4

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 5



Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 6

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 7

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 8

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 9

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 10

Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 11

Company Strength

          Kaiping Zhonghe Machinery Manufacturing Co., Ltd, is a manufacturing and trading combo that specializes in customizing different kinds of excavator boom arms and attachments We have more than 14000m' steel structure standardization workshop with a large number of high precision processing equipment as well as a strong and cohesive team. At present, there are more than 60 experienced technical staff, 30 welding workers with over 7 years of experience, 15 senior designers, and a high-tech R&D team.
          Our annual output of various types of excavator boom arms can reach 600sets. We supply products with high quality and moderate prices, which sell well in more than 40 countries and areas.
We adhere to" Merit Quality, Sincerity Management, and Customer Satisfaction", and honestly greet customers from home and abroad to negotiate and cooperate with us.
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 12
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 13
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 14
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 15
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 16
Custom Excavator Boom Arm , Volvo Excavator Attachments Long Reach Arm 17

FAQ of excavator long arm

Q1: Why not have boom and stick cylinders in the plan?
A1: First, the whole long arm is lengthening, but the boom just lengthening from its middle sleeve to its end, so the original boom and stick cylinder can be used. Second, using the original parts can save you cost.

Q2: How long is the boom arm can min excavator be configured with? Whether it is necessary to increase the counterweight?
A2. Generally speaking, the 30-40 excavator longest arm suggests to be 8 meters, and can configure 0.1 cbm bucket, with no need for an extra counterweight. 55 excavator's longest arm suggests to be 12 meters, which can configure 0.1-0.15 cbm bucket, which needs 0.5 ton extra counterweight. 60-80 excavator longest arm suggests to be 12 meters, can configure 0.15-0.25 cbm bucket, need 0.5-0.7 ton extra counterweight.
It is not recommended to extend boom arm to longes the t length as mini excavator is easy to slosh.

Q3: How long will it take tall an excavator long reach boom?
It depends on the installer and machine size.
Usually disconnecting the original boom arm, stick cylinder, then pin the new one is okay.
Kindly remind, use
 to prepare several containers to fill the oil before disassembling.
