Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder

Place of Origin Guangdong, China
Brand Name ZH
Certification CE
Model Number ZH-JCB22
Minimum Order Quantity 1set
Price $14000/Pieces
Packaging Details Bubble bag packaging
Delivery Time 15works
Supply Ability 60 Piece/Pieces per Month
Product Details
Condition 100% Brand New Material Q355B/Q690D Optional
Application All Brand Excavator Length 16-30m Optional
Payment Terms T/T, Discussion Delivery Time 15 Working Days
Packaging Details Bubble Bag Packing Certification CE Certificate
Brand Name Zhonghe Port Shenzhen Yantian (Port)
High Light

Q355B Long Reach Boom And Stick

,

Excavator Long Reach Boom And Stick

,

16m Excavator Boom Arm

Leave a Message
Product Description

Two Section 40-47T Stick Extension Long Reach Komatsu Excavator Attachments


See what Zhonghe can do: Catalogue ZH excavator boom arm.pdf
For more products:

Product Presentation of Excavator Boom

       The boom of the excavator is made of Q355B steel, which has good strength and stiffness. The extension arm sleeve is generally made of 45 # steel and lined with 40Cr bushing. In addition, the grease lubrication reduces the shear force generated by the frequent rotation of the shaft and sleeve, thus improving the service life of the sleeve. An extension arm is arranged between the main body support and the working arm. The boom is connected and supported by the oil cylinder, which increases the work of the boom cylinder and bucket oil cylinder. There are corresponding control systems inside and outside the cabin, and one set of oil cylinders matches one set of oil cylinders. It is especially suitable for mines, docks, warehouses, flood prevention and emergency rescue and special occasions. This is a major breakthrough in the transformation of mining machinery and has great practical value.

 Material Use  Q345B, Q550D, Also can customize to customer requirements
 Product Warranty Period  6 months,9 months,1 Year
 Product Size  Most lengths can be 34M, According to customer requirements, Any excavator model



Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 0



Advantages of Zhonghe Excavator Long Arm

1. Less maintenance

High quality materials are used, such as Q355B (default), Q690D (optional), Ningbo connector, seamless precision pipe, graphite alloy copper sleeve and solid but lightweight bucket cylinder.



2. Firm and durable

Built in stiffeners. Professional welding skills for different bearing positions. Groove preparation before welding (45 ° edge mining).



3. Tolerance is within 5-10um

The drilling tolerance is within 5-10um to ensure accuracy.



4. Deeper and higher

The maximum operating range and the maximum digging height are greater because the angle between the boom and the boom can reach 163 degrees.



5. High working efficiency and fuel saving

It is lighter while considering the mass, which not only ensures work efficiency but also saves fuel.



6. Fillet weld test

We can determine the quality of fillet welds by performing non-destructive testing and mechanical testing. Macro inspection and fillet weld fracture tests can well observe the weld contour, fusion, and penetration, and reveal whether there are any defects in the weld, such as pores or inclusions. These tests are used to test the welder's ability to weld fillet welds.

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 1

What Zhonghe Can Do



Custom made:
1. Applicable to all brands of excavators.
2. Color, length, and material can be made according to you.
3. Additional piping can be added to accommodate some additional applications.
4. Boom cylinders and stick cylinders can also be provided according to customer needs.



Strong production capacity:
We can produce 50 sets of excavator arms per month.
The annual output is 600 sets of various types of excavator arms.



Good service:
1. Online support within 24 hours.
2. Make an appointment for video technical support.
(Our engineers focus on excavator arms and attachments for more than 10 years)
3. The long arm of the excavator should be a two-section/three-section joint, which can be loaded into a container to save freight.



Warranty:
1 year for the long arm, 180 days for the cylinder and connecting rod, 90 days for the bucket.



Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 2

All parts you needed are included.

Long Reach Kits Are Fully Compatible with ZHONGHE Excavator Standard Buckets, and Cylinder.
Excavator long boom
Excavator long arm
Standard bucket
Linkage kit
Bucket cylinder
Butter hose
Pin
Lubricating system
Seals



Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 3



Specification of Excavator Boom Arm

Weight
Model
Part Length
Total length(m)
Weight(kg)
Maximum removal height(m)
Total Length(mm) 25T 8.5 16 2800 16M
Boom(A)(mm) 2.3 900
Arm(b)(mm) 5.2 1700
Maximum Digger Radius(C)(mm) 30T 9.5 18 3000 18M
Maximum Digger Depth(C)(mm) 2.3 1000
Maximum Unloading Height(E)(mm) 5.2 1950
Maximum Digger Height(F)(mm) 35T 10.5 20 3500 20M
Bucket Volume(m³) 2.3 1100





Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 4

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 5



Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 6

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 7

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 8

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 9

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 10

Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 11

Company Strength

          Kaiping Zhonghe Machinery Manufacturing Co., Ltd, is a manufacturing and trading combo that specializes in customizing different kinds of excavator boom arms and attachments We have more than 14000m' steel structure standardization workshop with a large number of high precision processing equipment as well as a strong and cohesive team. At present, there are more than 60 experienced technical staff, 30 welding workers with over 7 years of experience, 15 senior designers, and a high-tech R&D team.
          Our annual output of various types of excavator boom arms can reach 600 sets. We supply products with high quality and moderate prices, which sell well in more than 40 countries and areas.
We adhere to" Merit Quality, Sincerity Management, and Customer Satisfaction", and honestly greet customers from home and abroad to negotiate and cooperate with us.
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 12
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 13
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 14
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 15
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 16
Custom Hitachi Excavator Long Reach Boom And Stick With Cylinder 17

FAQ of excavator long arm

Q1: Why not have boom and stick cylinders in the plan?
A1: First, the whole long arm is lengthening, but the boom just lengthening from its middle sleeve to its end, so the original boom and stick cylinder can be used. Second, using the original parts can save you cost.

Q2: How long is the boom arm can min excavator be configured with? Whether it is necessary to increase the counterweight?
A2. Generally speaking, the 30-40 excavator longest arm suggests to be 8 meters, and can configure 0.1 cbm bucket, with no need for an extra counterweight. 55 excavator's longest arm suggests to be 12 meters, which can configure 0.1-0.15 cbm bucket, which needs 0.5 ton extra counterweight. 60-80 excavator longest arm suggests to be 12 meters, can configure 0.15-0.25 cbm bucket, need 0.5-0.7 ton extra counterweight.
It is not recommended to extend boom arm to longes the t length as mini excavator is easy to slosh.

Q3: How long will it take tall an excavator long reach boom?
It depends on the installer and machine size.
Usually disconnecting the original boom arm, stick cylinder, then pin the new one is okay.
Kindly remind, use
 to prepare several containers to fill the oil before disassembling.
