Product Details:
|
| Main Material: | Q355B Steel | Color: | Red, Blue, Yellow, As Your Request |
|---|---|---|---|
| Length: | 4m-12m | Weight: | 200-3000 |
| Bucket Capacity: | 0.1 Cbm-1.2 Cbm | Characteristic: | Durable |
| High Light: | Multiple Functions Excavator Sliding Arm,Durable Sliding Excavator Arm,Sliding Excavator Arm For Komatsu |
||
Catalogue ZH excavator boom arm.pdf
How it works
The excavator sliding arm is extended and retracted by the go and back of oil cylinder, to gain a bigger digging radius and digging depth.
The outer telescopic arm is composed of two parts: the upper sliding arm and the lower fixed arm.
The upper sliding arm is installed above the lower fixed arm, and the movable body is formed up and down by both sides rollers and rails.
By the expansion and contraction of the telescopic cylinder, the upper sliding body is pushed forward and backward to freely expand and contract.
Structure
A telescopic cylinder is installed in the upper sliding arm, the cylinder body is fixed on the lower fixed arm, and the cylinder piston rod is fixed on the upper sliding arm.
Its main components are: fixed body, moving body, slider, telescopic cylinder, etc.
Characteristic
Our sliding arm is durable and can do heavy work and dig hard soil. The sliding arm has a simple structure, low failure rate, easy maintenance and longer service life. Basically, if the sliding arm is under normal maintenance, the slider only needs to be replaced once a year, and other issues do not need to be considered. The sliding arm can be used for diagonal digging or support.
| Excavator Ton | (A)Maximum working Length of arm | (B)Maximum digging height | (C)Maximum digging radius(mm) | Bucket Volume(cbm) | Counter Weight(Ton) |
| 12-15T | 5700 | 8000 | 10400 | 0.2-0.3 | |
| 20-25T | 9150 | 10100 | 13000 | 0.4-0.7 | |
| 20-25T | 11000 | 12300 | 15200 | 0.4-0.7 | 1-2T |
| 30-35T | 11000 | 12000 | 15800 | 0.6-0.9 | |
| 40-45T | 12100 | 16000 | 19200 | 0.8-1.3 |
(Easy to maintain)
ZHONGHE silding arm adopt antiwear nylin sliding plates rather than traditional pulley, which can be replaced quickly and conveniently.
(Robust sliding structure)
1. The lower cover of the upper sliding arm and the upper cover of the lower fixing arm are both 20mm.
2. Cover plates are cut from a whole piece but not spliced, so as to be more firm and not easay to deform.
(Avoid oil leakage)
The double oil seal design for the built-in telescopic cylinder prevents hydraulic oil from leaking, prolongs the service life of the sliding cylinder
(Long service life)
1.Double limit design of the sliding cylinder prevents cylinder jolting and over pulling.
2.Steel sliders are welded between the skateboards to resists wear.
GOOD SERVICE:
1. Online support within 24 hours.
2. Appointment video technical support.
(Our engineers have focused on excavator boom and attachment over 10 years)
3. Long excavator boom shall be two/three jointed pcs to make it fittable into container to save shipping cost.
WARRANTY
6 months for sliding boom, 3 months for the bucket
Please feel free to contact Aria directly!
Whatsapp/Wechat:+86 13822325403
Email:excavatorlongarm@gmail.com
Contact Person: Miss. Katherine
Tel: +8618127538971
