Product Details:
|
| Condition: | Brand New Product | Operating Weight: | 5748kg |
|---|---|---|---|
| Bucket Capacity: | 0.43 Cbm | Max Digging Radius: | 6451mm |
| Maximum Digging Depth: | 4651mm | Moving Type: | Excavators |
| After-sales Service Provided: | Video Support Service | Maximum Digging Height: | 5941mm |
| Machine Weight: | 5750kg,6281mm | Color: | Yellow, Black, Orange |
| Product Name: | Telescopic Arm Long Reach Boom | Keywords: | Long Reach Boom For Sale |
| High Light: | Long Excavator Telescopic Boom Arm,Excavator Telescopic Boom Arm With Clamshell,6451 mm Excavator Boom Arm |
||
Email: Katherine@excavatorboomarm.com
The introduce of extended telescopic arm
Extendable Reach: The primary advantage of an extended telescopic arm is its ability to extend and retract, allowing the machinery to reach greater heights or distances. This versatility enables operators to access areas that would otherwise be challenging or inaccessible with a fixed-length arm.
Adjustable Length: The telescopic arm comprises multiple sections that can slide or telescope in and out. Operators can easily adjust the length of the arm based on the specific requirements of the task at hand. This adaptability enables precise positioning and efficient operation in different working conditions.
Increased Versatility: The extended telescopic arm enhances the versatility of the machinery, making it suitable for a wide range of applications. It allows for lifting loads at varying heights, reaching over obstacles, or accessing confined spaces, providing flexibility in different work environments.
Compact Design: When retracted, the telescopic arm can be compact, reducing the overall length of the machinery. This feature is beneficial for transportation, storage, and maneuvering in confined spaces, as it helps to minimize the equipment's footprint.
Enhanced Efficiency and Productivity: The extended reach provided by the telescopic arm eliminates the need for additional equipment or manual labor in certain situations. It reduces the time and effort required to reposition the machinery, resulting in improved efficiency and productivity on the job site.
Improved Safety: The extended telescopic arm allows operators to maintain a safer distance from potential hazards while performing lifting or access tasks. It minimizes the risk of accidents or collisions, providing a safer working environment for both operators and bystanders.
Q1: Why not have boom and stick cylinders in the plan?
A1: First, the whole long arm is lengthening, but the boom just lengthening from its middel sleeve to its end, so the original boom and stick cylinder can be used. Second, using the original parts can save your cost.
Q2: How long is the boom arm can min excavator be be configured with? Whether it is necessary to increase the counterweight?
A2. Generally speaking, 30-40 excavator longest arm suggests to be 8 meters, can configure 0.1 cbm bucket, no need extra counterweight. 55 excavator longest arm suggests to be 12 meters, can configure 0.1-0.15 cbm bucket, need 0.5 ton extra counterweight. 60-80 excavator longest arm suggests to be 12 meters, can configure 0.15-0.25 cbm bucket, need 0.5-0.7 ton extra counterweight.
It is not recommended to extend boom arm to longest length as min excavator is easy to sloshing.
Q3: How long will it takes to install a excavator long reach boom?
It depends on the installer and machine size.
Usually disconnect the original boom arm, stick cylinder, then pin the new one is okay.
Kindly remind, prepare several containers to fill the oil before disassemble.
